208R4-A/T n KIT transfo 208RALLY4 Asph/terre

Not rated
Availability On demmand
Code: 208R4-A/T
286 839 Kč / set
208R4-A/T n KIT transfo 208RALLY4 Asph/terre
Not rated

KIT CONTENTS:

Référence Designation Qté
3297-33 WHEEL HUB FIXING NUT Ø24x150 2
9808870380 LOCK CAP NUT STUB AXLE 2
329703 HOLDING PIN 2
904639768A SUPPORT AXE POINT D TERRE 2
1E1321055B Front gravel caliper mounting spacer 4
904640948B FRONT GRAVEL DAMPER 2
1E1421381A Ball joint spacer (up) 2
1E1421380A Ball joint spacer (down) 2
1E1420809A Front spring 40 N/mm 2
1E2221216A Rear Stone Guard 2
30713 Collar Screw M6x100-18 8
693586 Self Locking Nut M6 8
904667648A REAR RIGHT STONE GUARD BRACKET 1
904667658A REAR LEFT STONE GUARD BRACKET 1
691390 Socket Screw M8x125-16 4
904640978B REAR GRAVEL DAMPER 2
1E2521149B Rear damper spacer 2
1E2521281A Rear spring 36 N/mm 2
1E3120996D Gravel wheel Speedline 6x15 ET30 12
1E3121373A TYRE VALVE SCHRADER TR412 4
4249J6 VENTILATED BRAKE DISC Ø283x26 2
904666588A BRAKE DISC SPACER MONOBLOCK GRAVEL 2
904666598A BRAKE DISC SHIM MONOBLOCK GRAVEL 2
904639358A FRONT ANTIROLL BAR D15 1
PS85572A10 Countersunk M6x100 L30 screw 4
REFERENCEMENT referencing in progress 1
904642108A REAR BRAKE PAD SET 1
904650268A FRONT RIGHT ROCKER PANEL PROTECTION 1
904650278A FRONT LEFT ROCKER PANEL PROTECTION 1
904650288A REAR RIGHT ROCKER PANEL PROTECTION 1
904650298A REAR LEFT ROCKER PANEL PROTECTION 1
6922-73 Th screw ø6x100-12 10
904638258A LEFT FLOOR COVERING 1
904638268A RIGHT FLOOR COVERING 1
692254 Screw with washer M6x100-L18 22
904639718D REAR CROSS PROTECTION 1
904484598A Heatshield protection 1067X711 EP3 1
904643408B FRONT MUD FLAP 2
692330 SCREW TH RDL M6 L20 10
904658268A FLAP UPPER BRACKET 2
904657528A FLAP RIGHT BRACKET 1
904657538A FLAP LEFT BRACKET 1
6923H0 SELF LOCKING SELF-TAP SCREWS M6x16 4
CS250041ST H Nylstop Nut M6x100 6
CS250041ST H Nylstop Nut M6x100 4
CS250041ST H Nylstop Nut M6x100 4
1E1420810A Gravel Front Spring 35.5N/mm 2
904659378A FRONT SUSPENSION SPRING 31 N/mm 2
1E2521282A Rear Spring 32N.mm (Gravel) 2
904659388A Rear Spring 28N.m (Gravel) 2

Additional parameters

Category: Transformation kit Tarmac to Gravel
Weight: 200 kg
